Passenger Elevator Manufacturer in China
Passenger elevators for low- to high-rise buildings
Custom Capacity
800kg to 1630kg flexible configurations for different building needs.
Smooth Performance
VVVF control system ensures stable, quiet and efficient operation.
Smart Control
Intelligent elevator calling system improves traffic efficiency.
Global Service
Complete logistics and after-sales support for international projects.
Customized Passenger Elevator for Various Application
I need to know your use case:
We customize parameters based on the scenario:
- Load capacity
- Speed
- Group control functionality
Hospital accessibility + stretcher transport required; Braille buttons/voice announcements.
Building Compatibility
Obtain building shaft drawings (dimensions, load-bearing capacity, top floor height, pit depth);
Number of floor stops (including underground floors)
Customize passenger lifts details
We will provide you with:
Core configuration: control system, traction motor, door operator, and other brands/models.
Drawing verification: car dimensions, hoistway layout, electrical schematics, and confirmation of compliance with building requirements and local standards.
Cost breakdown: A detailed quote covering the elevator, certification, packaging, logistics, and other aspects, with an indication of "included" and "excluded" items.Contact now
Find the Right Elevator Solution for Your Project
As a professional passenger elevator manufacturer, we offer a full range of solutions including passenger elevators, freight elevators, and fully customized systems for different building requirements. Our factory delivers high-quality gearless traction elevators with fast lead times, flexible minimum order quantities, and reliable OEM/ODM support.
SMR Passenger Lift （The table shows only part of）
| Load (kg) | Speed (m/s) | Cabin Size (CW×CD) | Door Opening (EW×EH) | C.W. layout | Door type | Hoistway Shaft (HW×HD) | Pit depth (mm) | Top Floor Height (mm) |
| 450 | 1 | 1100*1100 | 700*2100 | C.W. at rear | CO | 1600*1800 | 1350 | 4400 |
| 630 | 1.5 | 1400*1100 | 800*2100 | C.W. at rear | CO | 1900*1700 | 1400 | 4500 |
| 630 | 1.75 | 1400*1100 | 800*2100 | C.W. at rear | CO | 1900*1700 | 1400 | 4600 |
| 800 (825) | 1 | 1400*1950 | 800*2100 | C.W. at rear | CO | 1900*1950 | 1400 | 4450 |
| 800 (825) | 1.5 | 1400*1950 | 800*2100 | C.W. at rear | CO | 1900*1950 | 1400 | 4500 |
| 800 (825) | 1.75 | 1400*1950 | 800*2100 | C.W. at rear | CO | 1900*1950 | 1400 | 4600 |
| 1000 (1050) | 1.5 | 1400*1800 | 900*2100 | C.W. at side | CO/Double entrance | 2300*2100 | 1400 | 4500 |
| 1000 (1050) | 1.75 | 1400*1800 | 900*2100 | C.W. at side | CO/Double entrance | 2300*2100 | 1400 | 4600 |
| 1000 (1050) (Bed lift) | 1 | 1100*2100 | 900*2100 | C.W. at side | SO | 1850*2550 | 1400 | 4500 |
| 1000 (1050) (Bed lift) | 1.5 | 1100*2100 | 900*2100 | C.W. at side | SO | 1850*2550 | 1400 | 4500 |
| 1000 (1050) (Bed lift) | 1.75 | 1100*2100 | 900*2100 | C.W. at side | CO | 2050*2500 | 1400 | 4600 |
MRL Passenger Lift（The table shows only part of）
| Load (kg) | Speed (m/s) | Cabin Size (CW*CD) | Door Opening (EW*EH) | C.W. layout | Door type | Hoistway/Shaft (HW*HD) | Pit depth (PD, mm) | Top Floor Height (TFH, mm) |
| 450 | 1 | 1100*1100 | 700*2100 | C.W. at side | CO | 1900*1500 | 1500 | 4250 |
| 450 | 1.75 | 1100*1100 | 700*2100 | C.W. at side | CO | 1900*1500 | 1600 | 4350 |
| 630 | 1.5 | 1100*1400 | 700*2100 | C.W. at side | CO | 1850*1850 | 1500 | 4250 |
| 630 | 1.75 | 1100*1400 | 700*2100 | C.W. at side | CO | 1850*1850 | 1600 | 4350 |
| 800 (825) | 1.5 | 1350*1400 | 800*2100 | C.W. at side | CO | 2100*1850 | 1500 | 4250 |
| 1000 (1050) | 1.5 | 1600*1450 | 900*2100 | C.W. at side | CO | 2350*1900 | 1500 | 4250 |
| 1000 (1050) (Bed lift) | 1.75 | 1100*2100 | 900*2100 | C.W. at side | SO | 1850*2550 | 1600 | 4500 |
| 1000 (1050) (Bed lift) | 1 | 1100*2100 | 900*2100 | C.W. at side | CO | 2100*2500 | 1500 | 4350 |
| 1000 (1050) (Bed lift) | 1.5 | 1100*2100 | 900*2100 | C.W. at side | CO | 2100*2500 | 1600 | 4450 |
| 1000 (1050) (Bed lift) | 1.75 | 1100*2100 | 900*2100 | C.W. at side | CO | 2100*2500 | 1600 | 4500 |
Customized Passenger Elevator Type
Machine Room Passenger Elevators Manufacturer
Load (kg): 450~2000
Speed (m/s): 1.0-1.75
Machine Room Passenger Elevators Manufacturer
Load (kg): 450~2000
Speed (m/s): 1.0-1.75
Panoramic Elevators Manufacturer
Load (kg): 630-1600
Speed (m/s): 1.0-1.75
High speed Elevator Manufacturer
Load (kg): 630-1600
Speed (m/s): 1.0-4.0
Personalized Cabin customization
Cabin design
Ceiling design
Global Elevator Project Cases
Proven Solutions Delivered for Commercial & Residential Buildings Worldwide
-
![School Elevator]()
School ElevatorPassenger Capacity: 1,000 kg – 2,500 kg (13 – 33 Persons). Rated Speed: 1.0 m/s – 2.5 m/s (Smooth gearless traction drive). Control System: Smart VVVF Microcomputer Control. Safety Compliance: Full
-
![1350kg Passenger Lift]()
1350kg Passenger LiftLoad Capacity: 1350 kg (18 Persons). Speed: 1.0 m/s – 2.5 m/s (Configurable). Stops / Floors: Up to 20+ Floors (Commercial Standard). Drive Type: Permanent Magnet Synchronous Gearless (PMSM). Control
-
![1.0m/s Traction Passenger Elevator]()
1.0m/s Traction Passenger ElevatorRated speed: 1.0m/s. Load range: 450kg-1050kg (6-14 passengers). Operation mode: 24h continuous frequent operation. Application environment: Residential, hotel, office, commercial public buildings.
-
![Energy-efficient Passenger Elevators]()
Energy-efficient Passenger Elevatorsenergy-efficient passenger elevators are designed with advanced technology to reduce energy consumption while providing reliable and smooth vertical transportation. These elevators significantly
-
![Elevator For Residential & Commercial Use]()
Elevator For Residential & Commercial UseSUS304 stainless steel cabin panels (0.8–1.5 mm), mounted on steel car frame. Hairline finish (Ra 0.2–0.5 μm), linear grain surface treatment. Rated load 630–1600 kg (8–21 persons). Speed range
-
![Passenger Elevator For 8 Persons Capacity 630 Kg]()
Passenger Elevator For 8 Persons Capacity 630 KgSUS304 stainless steel cabin panels (0.8–1.5 mm), mounted on steel car frame. Hairline finish (Ra 0.2–0.5 μm), linear grain surface treatment. Rated load 630–1600 kg (8–21 persons). Speed range
-
![Standard Residential Elevator]()
Standard Residential ElevatorSUS304 stainless steel cabin panels (0.8–1.5 mm), mounted on steel car frame. Hairline finish (Ra 0.2–0.5 μm), linear grain surface treatment. Rated load 630–1600 kg (8–21 persons). Speed range
-
![Passenger Elevators For Office, Hotel & Residential Projects]()
Passenger Elevators For Office, Hotel & Residential ProjectsSUS304 stainless steel cabin panels (0.8–1.5 mm), mounted on steel car frame. Hairline finish (Ra 0.2–0.5 μm), linear grain surface treatment. Rated load 630–1600 kg (8–21 persons). Speed range
China Passenger Elevator Factory & Suppliers
Best Elevator Exporter from China
Suzhou Volkspace Intelligent Equipment Co., LTD is a professional elevator factory and supplier based in Suzhou, China, specializing in the entire process of R&D, design, production, sales, and service. As one of China's top ten elevator manufacturers, we provide one-stop elevator solutions to customers worldwide, encompassing a wide range of products, including passenger elevators, elevator gearless traction machine, home elevators, villa elevators, hospital elevators, freight elevators, and more.
Strong manufacturing capabilities
Fast delivery
High customization
Excellent value for money
What does regular elevator maintenance include?
Regular maintenance is performed every two weeks to ensure safe and stable operation. It includes:
- Inspection of electrical control systems
- Check of traction machine, wire rope, and guide rails
- Testing of safety devices (speed limiter, safety gear, buffer)
- Door system inspection
- Lighting and ventilation check
- Operation data analysis and fault prevention
This helps reduce downtime, extend service life, and ensure long-term reliability.
What is your minimum order quantity (MOQ)?
We support no minimum order quantity — even 1 unit is available.
This is suitable for:
Distributors testing the market
Contractors with small projects
We also offer better pricing for bulk and long-term orders.
What is your lead time? Can you handle urgent orders?
Quotation: within 1 hour
Production: 7–14 days
For urgent projects, we can prioritize production and arrange fast delivery.
How much does a 3-passenger lift cost?
Prices vary depending on configuration:
Home use: $2,000 – $3,500
Light commercial (MRL): $5,000 – $12,000
Residential with installation: $20,000 – $35,000
High-end/custom: $70,000+
Final price depends on specifications, height, and customization.
Can elevator dimensions be customized?
Yes, we provide fully customized solutions.
We design based on:
Shaft dimensions
Building structure
Project type
Simply provide drawings or requirements, and we will deliver a suitable solution.
Contact now
How to choose the right service plan?
You can choose based on your needs:
- Half-inclusive plan: Lower cost, partial parts coverage
- All-inclusive plan: Full maintenance and parts replacement
We provide custom recommendations to match your budget and usage.
How do you ensure product quality?
We follow strict quality control:
Use certified materials and components
Full-process production inspection
Multiple safety and performance tests before delivery
This ensures long-term stability and safety.
Do you support distributors?
Yes, we welcome global partners.
We offer:
- Factory-direct pricing
- OEM/ODM support
- Flexible cooperation models
We aim to build long-term win-win partnerships.
How much does a custom passenger elevator cost?
Pricing depends on:
Load capacity (630kg / 800kg / 1000kg)
Speed (1.0–1.6 m/s or higher)
Building height and stops
Cabin design and materials
Features (MRL, smart control, etc.)
We provide:
1-unit MOQ
7–14 days delivery
1-hour quotation
We're professional passenger elevator manufacturers and suppliers in China, specialized in providing high quality custom service. We warmly welcome you to wholesale cheap passenger elevator from our factory.
